Electric Vertical Wheelchair Platform Lift

Ask Lasest Price
Brand Name :	SDLIFT
Model Number :	SJG0.25-3.5
Certification :	CE, ISO9001, SGS
Price :	US1980- USD4800 / UNIT
Supply Ability :	3600units per year
Delivery Time :	5-15 work days

Add to Cart

Product Details
Company Profile

Electric Vertical Wheelchair Platform Lift

Electric Wheelchair Vertical Lifting platform Wheelchair lifter with CE

with 2 Years Warranty:

Application:
The Electric Wheelchair Vertical Lifting platform Wheelchair lifter provides convenient, reliable and safe access between different levels, supporting a wide selection of application.
It is divided into two types according to material, which Spray type and Stainless Steel type.
Characterized by novel design, perfect stability and safety, nice appearance, low noise and so on, with 1.0 - 6.0m working range, 150-350kg carrying capacity. Ideal for indoor and outdoor application.

Technical Parameters:

Platform size	1200mm(L)* 1000mm(W)
Dimension	1200mm(L)1450mm(W) Travel height +700-1100 mm(H)
Max Platform Height	1000mm to 6000mm
Min Platform height	60mm
Configuration	Open through or front and side entrances
Speed	60mm/s
Load capacity	250KG~350KG
Control voltage	24V/DC
Power Output	2.2KW
Power Input	220V/50HZ/25A (or customized for local power supply)
Drive System	Hydraulic or screw
Control Mode	Inching Switch or Automatic
Drive Control	Self-resetting system
Overload	Protection Over current relay
Material of Platform	Plastic electrostatic spraying
Painting	Plastic electrostatic spraying
Guard panel & drive cabinet (framework)	Aluminum Alloy / 304 stainless steel
Operation Panel	Polished aluminum Alloy
Safety Wane Working Range	75°
Working Condition	Both indoors and outdoors
Working temperature	From -10°~60°C
Installation	Non-pit installation, directly fixed to concrete floor (the concrete floor below the platform shall not be lower than the ground)
Control Device	Calling box (installed on the wall nearby) and remote controller(Extra optional)
Emergency Stop	The lifting and lowering process can be stopped immediately by pressing the emergency button.
Safety device	Safety Interlock	Lock the platform when it is out of control
	Safety Sensor	The operation must be stopped immediately the safety edge meets obstacles during operation .
	Emergency lowering	The platform can be lowered by opening hydraulic valve manually or rolling screw rod.
	Auto-flap	Turn up after lifting

Wheelchair Lift Sketch Map:

Product pictures:

The Certificate:

CE Car Lift for sale Hydraulic Car Scissor Lift with high strength Mn Steel

Our services:

1) We can design the Electric Wheelchair Vertical Lifting platform Wheelchair lifter as per your requirement.
2) The most suitable Electric Wheelchair Vertical Lifting platform Wheelchair lifter will be recommended to you once we get your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
