250kgs 4M Wheelchair Platform Lift Elevator Disable Wheelchair Lift Platform for Home Use

Ask Lasest Price
Brand Name :	SDLIFT
Model Number :	SJGL0.25-4
Certification :	CE, ISO9001, SGS
Price :	US1980- USD4800 / UNIT
Supply Ability :	1200units per year
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

250kgs 4M Wheelchair Platform Lift Elevator Disable Wheelchair Lift Platform for Home Use

250kgs 4M Wheelchair Lift Elevator Disable Wheelchair Lift Platform for Home Use:

Application:

The wheelchair lift elevator is a device to transport wheelchair or motorized scooter and individual from one floor to another. It allows user to move freely within a multi-floored building. It is widely used for home, indoor and outdoor of public building.

Customized product can be done as your request, please tell us load weight, lift height, and platform size, our engineer will design a suitable lift for you soon.

Technical Parameters:

Specification:
Model	SJG0.25-4
Load capacity	250kg
Max. Platform Height	4000mm
Platform size	1450mm(L)* 9000mm(W)
Dimension	1450mm(L)1250mm(W)4100mm(H)
Min Platform height	70mm
In and out	180°in and out
Self weight	850kg
Material	Stainless steel or aluminum alloy with Powder coating
Power Input	220V/50HZ/1PH/1.5KW
Convenient operation design:
Drive System	Hydraulic
Control Mode	Inching Switch
Drive Control	Self-resetting system
Calling device	Calling box (Located at ground and upstairs), remote controller (optional)
Column switch	Two column switches, one is on the ground floor, one on the first floor
Working temperature	From -10°~60°C
Overload	Protection over current relay
Automatic ramp	75°ramp Range
Working Condition	Both indoors and outdoors
Installation	Non-pit installation, directly fixed to concrete floor
Safety Device:
Safety Interlock:	Lock the platform when it is out of control
Emergency Stop	The lift can be stopped immediately in case of any emergency
Emergency Lowering	The platform can be lowered by manual down button in case of power failure
Safety Sensor	The lift will be stopped immediately if the safety edge meets obstacles when going down.
Auto-flap ramp	Turn up to max 75°and prevent the wheelchair outside

Pictures of lift chair for disabled:

Load capacity : 250kgs

Max. Platform Height: 4M

Platform size: 1450mm(L)* 900mm(W)

We can according to your request for your custom.

250kgs 4M Wheelchair Platform Lift Elevator Disable Wheelchair Lift Platform for Home Use

Product part of the show:

250kgs 4M Wheelchair Platform Lift Elevator Disable Wheelchair Lift Platform for Home Use

The customers visiting:

Our services:

1) We can design the wheelchair lift elevator as per your requirement.

2) The most suitable wheelchair lift elevator will be recommended to you once we get your requirement.

3) Shipment can be arranged from our port to your destination port.

4) Operation video can be sent to you if needed.

5) User-friendly English manual for machine installation using and maintenance.

6) 2 year warranty for whole machine without man-made faults.

7) We will send you parts for free if there are any non-human factors faults during warranty time.

8) Supply 24-hours technical assistance by email, telephone or other communication online.

9) We could reply you in 2 hours after received your any questions even on weekend and holiday.

Engineers are available to your country if necessary.

FAQ:

Delivery Time: 10 - 25 days
Payments: T/T and L/C, other kinds, pls contact with us
MOQ: 1 set
Trade term: FOB/CIF to your nearest seaport
Application field: Construction, shipyard, industrial, airport, municipal garden or others

I am waiting to service for you 24 hours a day!
